As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ205 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.661 Bore, 1.287 CD, 0.905 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Subaru, EJ Series, 3.661 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Subaru EJ205, 93.00 Bore, Dish, Set of 4 |
| Title |
JE Pistons - Subaru, EJ Series, 93.00 mm Bore, Piston Kit |
| Engine |
EJ SERIES |
| Compression Height |
1.287 |
| Forging Type |
FSR |
| Engine - Web |
EJ Series |
| Ringset Included |
Yes |
| Piston Pin Length |
2.250 |
| Piston Pin Wall Thickness |
0.180 |
| Engine Type |
ICE |
| Product Market |
Sport Compact |
| Piston Head Type |
Dish |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Volume |
-12.40 |
| Product Type |
Engine Piston Kit |
| Make |
SUBARU |
| Piston Pin Outside Diameter |
0.905 |
| Piston Pin Material |
5115 |
| Prop 65 Yes/No |
Yes |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Wrist Pin Outer Diameter |
0.905 |
| Second Compression Ring Thickness |
0.0480 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Average Weight |
367 |
| Add-On |
JG1001-3661 |
| Add-On |
905-2250-18-51S |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Subaru EJ Series Piston Kit - 93.00 mm Bore - 1.287 in. CH, -12.40 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
905-042-CT |
| Piston Quantity |
4 |
| Piston Material |
2618 |
| Industry |
Automotive |
| Cylinder Head |
EJ205 WRX |
| Bore Diameter |
93.00 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Subaru |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
