As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 5.0L Coyote |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Ford, Modular Ford, 3.640 in. Bore, 1.174 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.640 Bore, 1.174 CD, 0.866 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Ford 5.0L Coyote, 3.640 Bore, Dish, Set of 8 |
| Title - Web |
JE Pistons Ford Modular Piston Kit - 3.640 in. Bore - 1.174 in. CH, -17.80 CC |
| Piston Volume |
-17.80 |
| Industry |
Automotive |
| Product Type |
Engine Piston Kit |
| Cylinder Head |
MODULAR 5.0L COYOTE GEN 1/2 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Material |
2618 |
| Add-On |
JG1008-3642 |
| Engine |
Modular |
| Piston Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0480 |
| Out of Stock Message |
Call for Availability |
| Add-On |
866-2250-15-51C |
| Add-On |
866-063-MW |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Bore Diameter |
3.640 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Average Weight |
352 |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Compression Height |
1.174 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Make |
FORD |
| Ringset Included |
No |
| Engine Type |
ICE |
| Piston Quantity |
8 |
| Top Compression Ring Thickness |
0.0400 |
| Title |
JE Pistons - Ford, Modular, 3.640 in. Bore, Piston Kit |
| Piston Series |
JE Pistons |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Engine - Web |
Modular |
| Wrist Pin Length |
2.250 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
11.0000 |
