As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Audi 2.7L S4 TT |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.209 Bore, 1.210 CD, 0.827 Pin, Set of 1. |
| Description_EXT |
JE, Audi, 2.7L S4 TT, 3.209 in. Bore, 9.00:1, Inverted Dome/Dish, Right Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Audi 2.7L, 81.50 Bore, Dish, Set of 1 |
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Add-On |
827-063-MW |
| Add-On |
JG1001-3209 |
| Add-On |
827-2250-15-51C |
| Bore Diameter |
81.50 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>European |
| Make |
AUDI |
| Cylinder Head |
2.7L TT 5V |
| Forging Type |
Round |
| Engine |
2.7L S4 TT |
| Compression Height |
1.210 |
| Engine Type |
ICE |
| Industry |
Automotive |
| Make - Web |
Audi |
| Engine - Web |
2.7L S4 TT |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.250 |
| Piston Volume |
-3.90 |
| Piston Pin Outside Diameter |
0.827 |
| Product Type |
Engine Piston |
| Piston Quantity |
1 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Piston Series |
JE Pistons |
| Piston Head Type |
Dish |
| Piston Material |
2618 |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Average Weight |
298 |
| Piston Orientation |
Right |
| Ringset Included |
Yes |
| Product Market |
European |
| Oil Ring Thickness |
0.111 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Title |
JE Pistons - Audi, 2.7L S4 TT, 81.50 mm Bore, Piston |
| Title - Web |
JE Pistons Audi 2.7L S4 TT Piston - 81.50 mm Bore - 1.210 in. CH, -3.90 CC |
| Top Compression Ring Thickness |
0.0400 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.827 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
