As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Audi 2.7L S4 TT |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.189 Bore, 1.210 CD, 0.827 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_EXT |
JE, Audi, 2.7L S4 TT, 3.189 in. Bore, 9.00:1, Inverted Dome/Dish, Right Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Audi 2.7L, 81.00 Bore, Dish, Set of 1 |
| Description_SHO |
Piston |
| Add-On |
827-2250-15-51C |
| Add-On |
827-063-MW |
| Add-On |
JG1001-3189 |
| Bore Diameter |
81.00 |
| Cylinder Head |
2.7L TT 5V |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>European |
| Compression Height |
1.210 |
| Engine |
2.7L S4 TT |
| Industry |
Automotive |
| Forging Type |
Round |
| Engine Type |
ICE |
| Make |
AUDI |
| Engine - Web |
2.7L S4 TT |
| Piston Pin Wall Thickness |
0.150 |
| Piston Orientation |
Right |
| Piston Volume |
-3.30 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Outside Diameter |
0.827 |
| Out of Stock Message |
Call for Availability |
| Piston Series |
JE Pistons |
| Piston Average Weight |
302 |
| Piston Material |
2618 |
| Piston Quantity |
1 |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Dish |
| Make - Web |
Audi |
| Product Type |
Engine Piston |
| Title - Web |
JE Pistons Audi 2.7L S4 TT Piston - 81.00 mm Bore - 1.210 in. CH, -3.30 CC |
| Prop 65 Yes/No |
Yes |
| Ringset Included |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Title |
JE Pistons - Audi, 2.7L S4 TT, 81.00 mm Bore, Piston |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Product Market |
European |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.827 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
