As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 08-14 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.248 Bore, 1.165 CD, 0.827 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T TSI - 08-14 - 21mm Pin, 3.248 in. Bore, 9.10:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Volkswagen 2.0L Turbo, 82.50 Bore, Dish, Set of 4 |
| Wrist Pin Outer Diameter |
0.827 |
| Piston Series |
JE Pistons |
| Piston Head Type |
Dish |
| Piston Pin Material |
5115 |
| Piston Average Weight |
295 |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 82.50 mm Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Compression Height |
1.165 |
| Engine - Web |
2.0T TSI |
| Wrist Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Bore Diameter |
82.50 |
| Forging Type |
Round |
| Product Market |
European |
| Piston Volume |
-10.80 |
| Piston Pin Outside Diameter |
0.827 |
| Piston Pin Wall Thickness |
0.150 |
| Product Type |
Engine Piston Kit |
| Engine Type |
ICE |
| Piston Quantity |
4 |
| Make |
VOLKSWAGEN |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Engine |
2.0T TSI 04-08 21 mm Pin |
| Ringset Included |
Yes |
| Piston Material |
2618 |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
JG1001-3250 |
| Piston Pin Length |
2.250 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Add-On |
827-2250-15-51C |
| Cylinder Head |
2.0 TSI |
| Add-On |
827-063-MW |
| Out of Stock Message |
Call for Availability |
| Industry |
Automotive |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 82.50 mm Bore - 1.165 in. CH, -10.80 CC |
| Engine Detail |
2.0T TSI 04-08 21 mm Pin |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Volkswagen |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
