As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 2JZ-GTE/2JZ-GE |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.425 Bore, 1.338 CD, 0.866 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_EXT |
JE, Toyota, 2JZ-GTE, 3.425 in. Bore, 9.50:1, Inverted Dome/Dish, Single Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Description_TLE |
Toyota 2JZ-GE/2JZ-GTE, 87.00 Bore, Dish, Set of 1 |
| Description_INV |
JE Pistons, Piston |
| Add-On |
866-063-MW |
| Add-On |
JG1001-3425 |
| Add-On |
866-2250-15-51C |
| Bore Diameter |
87.00 |
| Industry |
Automotive |
| Forging Type |
FSR |
| Engine |
2JZ-GTE |
| Cylinder Head |
2JZ-GTE |
| Make |
TOYOTA |
| Compression Height |
1.338 |
| Engine Type |
ICE |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Engine - Web |
2JZ-GTE |
| Make - Web |
Toyota |
| Piston Quantity |
1 |
| Piston Series |
JE Pistons |
| Piston Pin Outside Diameter |
0.866 |
| Piston Material |
2618 |
| Product Market |
Sport Compact |
| Oil Ring Thickness |
0.111 |
| Piston Pin Length |
2.250 |
| Piston Average Weight |
337 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Head Type |
Dish |
| Piston Pin Material |
5115 |
| Piston Volume |
-8.90 |
| Product Type |
Engine Piston |
| Out of Stock Message |
Call for Availability |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0480 |
| Title |
JE Pistons - Toyota, 2JZ-GTE, 87.00 mm Bore, Piston |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0400 |
| Ringset Included |
Yes |
| Title - Web |
JE Pistons Toyota 2JZ-GTE Piston - 87.00 mm Bore - 1.338 in. CH, -8.90 CC |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
