As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Renault F7R CLIO |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.307 Bore, 0.984 CD, 0.708 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Renault, F7R, 3.307 in. Bore, 12.70:1, Dome, 4 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Renault F7R CLIO, 84.00 Bore, Dome, Set of 4 |
| Make |
RENAULT |
| Wrist Pin Wall Thickness |
0.120 |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Product Market |
European |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Pin Wall Thickness |
0.120 |
| Wrist Pin Outer Diameter |
0.708 |
| Piston Volume |
11.80 |
| Piston Series |
JE Pistons |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Oil Ring Thickness |
0.111 |
| Bore Diameter |
84.00 |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Compression Height |
0.984 |
| Piston Pin Material |
5115 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
0.708 |
| Piston Average Weight |
289 |
| Industry |
Automotive |
| Piston Quantity |
4 |
| Title |
JE Pistons - Renault, F7R, 84.00 mm Bore, Piston Kit |
| Prop 65 Yes/No |
Yes |
| Engine - Web |
F7R |
| Title - Web |
JE Pistons Renault F7R Piston Kit - 84.00 mm Bore - 0.984 in. CH, 11.80 CC |
| Out of Stock Message |
Call for Availability |
| Add-On |
708-2250-12-51C |
| Piston Material |
2618 |
| Piston Head Type |
Dome |
| Add-On |
708-050-MW |
| Piston Pin Length |
2.250 |
| Cylinder Head |
F7R |
| Ringset Included |
Yes |
| Engine |
F7R |
| Add-On |
JG1001-3307 |
| Make - Web |
Renault |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
