As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Citroen TU5J4 SAX |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.110 Bore, 1.280 CD, 0.767 Pin, Set of 4. |
| Description_EXT |
JE, Citroen, TU5J4, 3.110 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Citroen TU5J4 SAX, 79.00 Bore, Dish, Set of 4 |
| Piston Pin Wall Thickness |
0.130 |
| Engine - Web |
TU5J4 |
| Title |
JE Pistons - Citroen, TU5J4, 79.00 mm Bore, Piston Kit |
| Product Market |
Sport Compact |
| Piston Head Type |
Dish |
| Compression Height |
1.280 |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Top Compression Ring Thickness |
0.0400 |
| Bore Diameter |
79.00 |
| Ringset Included |
Yes |
| Piston Average Weight |
270 |
| Wrist Pin Wall Thickness |
0.130 |
| Forging Type |
Round |
| Second Compression Ring Thickness |
0.0480 |
| Make |
CITROEN |
| Piston Quantity |
4 |
| Piston Pin Outside Diameter |
0.767 |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.767 |
| Piston Material |
2618 |
| Add-On |
767-2250-13-TSC |
| Industry |
Automotive |
| Cylinder Head |
TU5J4 |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
767-050-MW |
| Piston Volume |
-15.40 |
| Prop 65 Yes/No |
Yes |
| Product Type |
Engine Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Citroen TU5J4 Piston Kit - 79.00 mm Bore - 1.280 in. CH, -15.40 CC |
| Engine |
TU5J4 |
| Add-On |
XC7900 |
| Make - Web |
Citroen |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
