As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet LS |
| Description_DEF |
Engine Piston |
| Description_EXT |
JE, Chevrolet, LS Gen III/IV, 4.010 in. Bore, 1.340 CD, Inverted Dome/Dish, Right Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 4.010 Bore, 1.340 CD, 0.945 Pin, Set of 1. |
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Chevrolet LS, 4.010 Bore, Dish, Set of 1 |
| Add-On |
945-073-MW |
| Add-On |
JG3108-4010-4 |
| Add-On |
945-2250-15-51C |
| Bore Diameter |
4.010 |
| Cylinder Head |
LS 12 DEG/15 DEG COMBO VR |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Compression Height |
1.340 |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Piston Series |
JE Pistons |
| Piston Quantity |
1 |
| Product Type |
Engine Piston |
| Engine |
LS Gen III/IV |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.1175 |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Volume |
-16.80 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Product Market |
Domestic |
| Piston Pin Length |
2.250 |
| Piston Pin Outside Diameter |
0.945 |
| Make |
CHEVROLET |
| Piston Orientation |
Right |
| Piston Average Weight |
435 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Engine - Web |
LS Gen III/IV |
| Title |
JE Pistons - Chevrolet, LS Gen III/IV, 4.010 in. Bore, Piston |
| Second Compression Ring Thickness |
0.0600 |
| Ringset Included |
No |
| Top Compression Ring Thickness |
0.0480 |
| Title - Web |
JE Pistons Chevrolet LS Gen III/IV Piston - 4.010 in. Bore - 1.340 in. CH, -16.80 CC |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.945 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
