As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 2AR-FE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.543 Bore, 1.372 CD, 0.866 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Toyota, 2AR-FE, 3.543 in. Bore, 11.00:1, Dome, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Toyota 2AR-FE, 90.00 Bore, Dome, Set of 4 |
| Product Market |
Sport Compact |
| Bore Diameter |
90.00 |
| Forging Type |
Round |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Piston Average Weight |
348 |
| Piston Series |
JE Pistons |
| Wrist Pin Wall Thickness |
0.150 |
| Compression Height |
1.372 |
| Engine Type |
ICE |
| Piston Quantity |
4 |
| Piston Pin Outside Diameter |
0.866 |
| Engine - Web |
2AR-FE |
| Wrist Pin Outer Diameter |
0.866 |
| Make |
TOYOTA |
| Add-On |
JG1001-3543 |
| Piston Pin Wall Thickness |
0.150 |
| Industry |
Automotive |
| Piston Volume |
-11.10 |
| Add-On |
866-2500-15-51C |
| Add-On |
866-063-MW |
| Title |
JE Pistons - Toyota, 2AR-FE, 90.00 mm Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Cylinder Head |
2AR-FE |
| Product Type |
Engine Piston Kit |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dome |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 Yes/No |
Yes |
| Piston Material |
2618 |
| Piston Pin Length |
2.500 |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Toyota 2AR-FE Piston Kit - 90.00 mm Bore - 1.372 in. CH, -11.10 CC |
| Engine |
2AR-FE |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.500 |
| Make - Web |
Toyota |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
