As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet 360 Sprint Brodix 11X |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.005 in. Bore, 1.250 CD, Dome, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.005 Bore, 1.250 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Chevrolet 360 BRODIX 11X, 4.005 Bore, Dome, Set of 8 |
| Ringset Included |
No |
| Prop 65 (C, R or CR) |
CR |
| Make - Web |
Chevrolet |
| Add-On |
927-2250-17-51C |
| Add-On |
927-073-MW |
| Add-On |
J71408-4000-5 |
| Second Compression Ring Thickness |
0.0440 |
| Engine |
Small Block |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Chevrolet Small Block Piston Kit - 4.005 in. Bore - 1.250 in. CH, 14.00 CC |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Material |
2618 |
| Piston Head Type |
Dome |
| Cylinder Head |
PRO ACTION 23 DEG |
| Industry |
Automotive |
| Piston Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Compression Height |
1.250 |
| Bore Diameter |
4.005 |
| Forging Type |
FSR |
| Top Compression Ring Thickness |
0.0435 |
| Piston Volume |
14.00 |
| Piston Series |
JE Pistons |
| Make |
CHEVROLET |
| Oil Ring Thickness |
0.119 |
| Piston Pin Wall Thickness |
0.170 |
| Piston Quantity |
8 |
| Product Type |
Engine Piston Kit |
| Title |
JE Pistons - Chevrolet, Small Block, 4.005 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.927 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Piston Average Weight |
434 |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.170 |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.250 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
