As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K20/K24 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Acura, K Series, 3.425 in. Bore, 10.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.425 Bore, 1.176 CD, 0.866 Pin, Set of 4. |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Honda K20/K24, 87.00 Bore, Dish, Set of 4 |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
318 |
| Bore Diameter |
87.00 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Acura K Series Piston Kit - 87.00 mm Bore - 1.176 in. CH, 7.40 CC |
| Cylinder Head |
K20 |
| Prop 65 Yes/No |
Yes |
| Add-On |
866-063-MW |
| Piston Material |
2618 |
| Add-On |
JG1001-3425 |
| Add-On |
866-2250-15-51C |
| Top Compression Ring Thickness |
0.0400 |
| Piston Quantity |
4 |
| Piston Volume |
7.40 |
| Second Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston Kit |
| Piston Pin Length |
2.250 |
| Industry |
Automotive |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Acura |
| Piston Series |
JE Pistons |
| Make |
ACURA |
| Title |
JE Pistons - Acura, K Series, 87.00 mm Bore, Piston Kit |
| Engine |
K Series |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.866 |
| Product Market |
Sport Compact |
| Oil Ring Thickness |
0.111 |
| Compression Height |
1.176 |
| Piston Head Type |
Dish |
| Engine - Web |
K Series |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
