As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda B Series VTEC |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Honda, B Series, 3.327 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.327 Bore, 1.181 CD, 0.827 Pin, Set of 4. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda B Series, 84.50 Bore, Dish, Set of 4 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Length |
2.250 |
| Engine |
B SERIES |
| Engine Type |
ICE |
| Title - Web |
JE Pistons Honda B Series Piston Kit - 84.50 mm Bore - 1.181 in. CH, -12.00 CC |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Head Type |
Dish |
| Piston Pin Wall Thickness |
0.150 |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Wrist Pin Outer Diameter |
0.827 |
| Make - Web |
Honda |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Quantity |
4 |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0480 |
| Top Compression Ring Thickness |
0.0400 |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
B18C |
| Make |
HONDA |
| Piston Volume |
-12.00 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.827 |
| Product Market |
Sport Compact |
| Piston Material |
2618 |
| Industry |
Automotive |
| Bore Diameter |
84.50 |
| Engine - Web |
B Series |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Piston Average Weight |
305 |
| Add-On |
JG1001-3327 |
| Compression Height |
1.181 |
| Add-On |
827-2250-15-51C |
| Title |
JE Pistons - Honda, B Series, 84.50 mm Bore, Piston Kit |
| Add-On |
827-063-MW |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
6.0000 |
