As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan CA18DET |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Nissan, CA18DET, 3.287 in. Bore, 8.50:1, Flat Top, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.287 Bore, 1.181 CD, 0.787 Pin, Set of 4. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan CA18DET, 83.50 Bore, Flat, Set of 4 |
| Wrist Pin Length |
2.250 |
| Product Type |
Engine Piston Kit |
| Piston Volume |
0.00 |
| Ring Set Included |
Yes |
| Add-On |
JG1001-3287 |
| Add-On |
787-2250-18-51C |
| Add-On |
787-050-MW |
| Second Compression Ring Thickness |
0.0480 |
| Cylinder Head |
CA18DET |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Engine |
CA18DET |
| Piston Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Nissan |
| Title - Web |
JE Pistons Nissan CA18DET Piston Kit - 83.50 mm Bore - 1.181 in. CH, 0.00 CC |
| Piston Pin Material |
5115 |
| Piston Average Weight |
296 |
| Forging Type |
FSR |
| Piston Quantity |
4 |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0400 |
| Piston Head Type |
Flat |
| Compression Height |
1.181 |
| Ringset Included |
Yes |
| Title |
JE Pistons - Nissan, CA18DET, 83.50 mm Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.180 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Oil Ring Thickness |
0.111 |
| Bore Diameter |
83.50 |
| Piston Series |
JE Pistons |
| Wrist Pin Outer Diameter |
0.787 |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Pin Outside Diameter |
0.787 |
| Make |
NISSAN |
| Engine Type |
ICE |
| Engine - Web |
CA18DET |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
