As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Audi 2.2L 20V Turbo I5 - RS2 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.209 Bore, 1.291 CD, 0.787 Pin, Set of 5. |
| Description_EXT |
JE, Audi, RS2 5 CYL, 3.209 in. Bore, 8.50:1, Inverted Dome/Dish, 5 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Audi 2.2L 20V Turbo I5 - RS2, 81.50 Bore, Dish, Set of 5 |
| Title |
JE Pistons - Audi, RS2 5 Cyl, 81.50 mm Bore, Piston Kit |
| Piston Average Weight |
285 |
| Make |
AUDI |
| Piston Pin Wall Thickness |
0.180 |
| Oil Ring Thickness |
0.111 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Series |
JE Pistons |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
European |
| Forging Type |
FSR |
| Bore Diameter |
81.50 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.787 |
| Piston Quantity |
5 |
| Piston Pin Outside Diameter |
0.787 |
| Product Type |
Engine Piston Kit |
| Piston Volume |
-8.30 |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Piston Pin Material |
5115 |
| Compression Height |
1.291 |
| Wrist Pin Wall Thickness |
0.180 |
| Ring Set Included |
Yes |
| Engine - Web |
RS2 5 Cyl |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
RS2 5CY |
| Engine |
RS2 5 CYL |
| Add-On |
787-050-MW |
| Add-On |
787-2250-18-51C |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Add-On |
JG1001-3209 |
| Title - Web |
JE Pistons Audi RS2 5 Cyl Piston Kit - 81.50 mm Bore - 1.291 in. CH, -8.30 CC |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Piston Pin Length |
2.250 |
| Ringset Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Audi |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
