As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Hyundai 3.8L V6 Genesis |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.780 Bore, 1.242 CD, 0.866 Pin, Set of 1. |
| Description_EXT |
JE, Hyundai, 3.8L V6 Genisis, 3.779 in. Bore, 9.00:1, Inverted Dome/Dish, Right Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston |
| Description_TLE |
Hyundai 3.6L V6 Genesis, 96.00 Bore, Dish, Set of 1 |
| Prop 65 (C, R or CR) |
CR |
| Make |
HYUNDAI |
| Compression Height |
1.242 |
| Top Compression Ring Thickness |
0.0480 |
| Piston Quantity |
1 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Orientation |
Right |
| Piston Pin Outside Diameter |
0.866 |
| Wrist Pin Outer Diameter |
0.866 |
| Engine - Web |
3.8L V6 Genesis |
| Cylinder Head |
LAMBDA V6 |
| Piston Volume |
-23.20 |
| Add-On |
866-2500-15-51C |
| Title |
JE Pistons - Hyundai, 3.8L V6 Genesis, 96.00 mm Bore, Piston |
| Piston Pin Material |
5115 |
| Piston Material |
2618 |
| Piston Average Weight |
382 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Product Type |
Engine Piston |
| Product Market |
Sport Compact |
| Bore Diameter |
96.00 |
| Industry |
Automotive |
| Add-On |
SWN30131-2 |
| Add-On |
866-063-MW |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.500 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Piston Series |
JE Pistons |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Hyundai 3.8L V6 Genesis Piston - 96.00 mm Bore - 1.242 in. CH, -23.20 CC |
| Oil Ring Thickness |
0.0995 |
| Forging Type |
Round |
| Piston Head Type |
Dish |
| Engine |
3.8L V6 Genesis |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Piston Pin Length |
2.500 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Hyundai |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
