As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda H22 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Honda, H Series, 3.445 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.445 Bore, 1.220 CD, 0.866 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda H22, 87.50 Bore, Dish, Set of 4 |
| Wrist Pin Length |
2.250 |
| Product Market |
Sport Compact |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
87.50 |
| Piston Quantity |
4 |
| Ring Set Included |
Yes |
| Cylinder Head |
H22A VTEC |
| Title |
JE Pistons - Honda, H Series, 87.50 mm Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Piston Material |
2618 |
| Compression Height |
1.220 |
| Piston Average Weight |
323 |
| Engine - Web |
H Series |
| Title - Web |
JE Pistons Honda H Series Piston Kit - 87.50 mm Bore - 1.220 in. CH, -6.20 CC |
| Add-On |
JG1001-3445 |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
866-2250-15-51C |
| Prop 65 Yes/No |
Yes |
| Add-On |
866-063-MW |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Piston Volume |
-6.20 |
| Industry |
Automotive |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Pin Wall Thickness |
0.150 |
| Out of Stock Message |
Call for Availability |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Make |
HONDA |
| Engine |
H SERIES |
| Piston Series |
JE Pistons |
| Wrist Pin Outer Diameter |
0.866 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Honda |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Piston Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
6.0000 |
