As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 2.0L Zetec |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.366 Bore, 1.171 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Ford, 2.0L ZETEC, 3.366 in. Bore, 11.00:1, Dome, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford Zetec 2.0L, 85.50 Bore, Dome, Set of 4 |
| Piston Pin Outside Diameter |
0.787 |
| Forging Type |
FSR |
| Wrist Pin Outer Diameter |
0.787 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dome |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Make |
FORD |
| Piston Pin Wall Thickness |
0.180 |
| Bore Diameter |
85.50 |
| Compression Height |
1.171 |
| Engine Type |
ICE |
| Product Market |
Sport Compact |
| Piston Quantity |
4 |
| Ringset Included |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Title |
JE Pistons - Ford, 2.0L ZETEC, 85.50 mm Bore, Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Wrist Pin Wall Thickness |
0.180 |
| Engine - Web |
2.0L ZETEC |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
2.0L ZETEC |
| Add-On |
JG1001-3366 |
| Title - Web |
JE Pistons Ford 2.0L ZETEC Piston Kit - 85.50 mm Bore - 1.171 in. CH, 4.50 CC |
| Piston Pin Length |
2.250 |
| Piston Volume |
4.50 |
| Prop 65 (C, R or CR) |
CR |
| Engine |
2.0L ZETEC |
| Piston Average Weight |
324 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Add-On |
787-050-MW |
| Out of Stock Message |
Call for Availability |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
787-2250-18-51C |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
