As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 2.0L Zetec |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.346 Bore, 1.171 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Ford, 2.0L ZETEC, 3.346 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford Zetec 2.0L, 85.00 Bore, Dish, Set of 4 |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Second Compression Ring Thickness |
0.0480 |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Oil Ring Thickness |
0.111 |
| Title - Web |
JE Pistons Ford 2.0L ZETEC Piston Kit - 85.00 mm Bore - 1.171 in. CH, -8.00 CC |
| Engine |
2.0L ZETEC |
| Piston Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Forging Type |
FSR |
| Piston Pin Wall Thickness |
0.180 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Quantity |
4 |
| Product Market |
Sport Compact |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.787 |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
787-2250-18-51C |
| Make |
FORD |
| Industry |
Automotive |
| Piston Material |
2618 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - Ford, 2.0L ZETEC, 85.00 mm Bore, Piston Kit |
| Bore Diameter |
85.00 |
| Out of Stock Message |
Call for Availability |
| Add-On |
787-050-MW |
| Compression Height |
1.171 |
| Piston Pin Outside Diameter |
0.787 |
| Piston Volume |
-8.00 |
| Cylinder Head |
2.0L ZETEC |
| Add-On |
JG1001-3346 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Average Weight |
303 |
| Product Type |
Engine Piston Kit |
| Engine - Web |
2.0L ZETEC |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
