Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 572 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.600 Bore, 1.465 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.600 in. Bore, 1.465 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 572, 4.600 Bore, Dome, Set of 8 |
| Ring Set Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Cylinder Head |
OPEN CHAMBER |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Length |
2.930 |
| Piston Volume |
29.25 |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Bore Diameter |
4.600 |
| Piston Pin Length |
2.930 |
| Piston Average Weight |
689 |
| Add-On |
S100S8-4600-5 |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.600 in. Bore - 1.465 in. CH, 29.25 CC |
| Prop 65 (C, R or CR) |
CR |
| Out of Stock Message |
Call for Availability |
| Add-On |
990-2930-15-51S |
| Add-On |
990-042-CS |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dome |
| Engine |
Big Block |
| Top Compression Ring Thickness |
0.0640 |
| Piston Pin Outside Diameter |
0.990 |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Ringset Included |
No |
| Title |
SRP - Chevrolet, Big Block, 4.600 in. Bore, Piston Kit |
| Oil Ring Thickness |
0.188 |
| Product Market |
Domestic |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.465 |
| Piston Series |
SRP |
| Make |
CHEVROLET |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Big Block |
| Wrist Pin Outer Diameter |
0.990 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
