As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda F22C |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Honda, F Series, 3.445 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.445 Bore, 1.181 CD, 0.905 Pin, Set of 4. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda F22C, 87.50 Bore, Dish, Set of 4 |
| Ringset Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine |
F SERIES |
| Piston Pin Length |
2.250 |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Make - Web |
Honda |
| Title - Web |
JE Pistons Honda F Series Piston Kit - 87.50 mm Bore - 1.181 in. CH, -16.10 CC |
| Make |
HONDA |
| Forging Type |
FSR |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Wall Thickness |
0.150 |
| Out of Stock Message |
Call for Availability |
| Product Market |
Sport Compact |
| Title |
JE Pistons - Honda, F Series, 87.50 mm Bore, Piston Kit |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
F20C1 |
| Add-On |
905-2250-15-51C |
| Add-On |
905-073-MW |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
0.905 |
| Piston Average Weight |
304 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Volume |
-16.10 |
| Top Compression Ring Thickness |
0.0400 |
| Bore Diameter |
87.50 |
| Industry |
Automotive |
| Add-On |
JG1001-3445 |
| Compression Height |
1.181 |
| Engine - Web |
F Series |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Piston Quantity |
4 |
| Piston Material |
2618 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
6.0000 |
