As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda F22C |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.425 Bore, 1.181 CD, 0.905 Pin, Set of 4. |
| Description_EXT |
JE, Honda, F Series, 3.425 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Honda F22C, 87.00 Bore, Dish, Set of 4 |
| Description_SHO |
Piston Kit |
| Add-On |
JG1001-3425 |
| Add-On |
905-073-MW |
| Add-On |
905-2250-15-51C |
| Bore Diameter |
87.00 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Engine |
F SERIES |
| Cylinder Head |
F20C1 |
| Compression Height |
1.181 |
| Engine Type |
ICE |
| Engine - Web |
F Series |
| Piston Pin Outside Diameter |
0.905 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Head Type |
Dish |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Piston Material |
2618 |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.111 |
| Piston Average Weight |
300 |
| Forging Type |
FSR |
| Industry |
Automotive |
| Make |
HONDA |
| Make - Web |
Honda |
| Ringset Included |
Yes |
| Product Market |
Sport Compact |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-15.40 |
| Piston Series |
JE Pistons |
| Title - Web |
JE Pistons Honda F Series Piston Kit - 87.00 mm Bore - 1.181 in. CH, -15.40 CC |
| Piston Quantity |
4 |
| Top Compression Ring Thickness |
0.0400 |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston Kit |
| Title |
JE Pistons - Honda, F Series, 87.00 mm Bore, Piston Kit |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
6.0000 |
