As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda F20C |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Honda, F Series, 3.445 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.445 Bore, 1.181 CD, 0.905 Pin, Set of 4. |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Honda F20C, 87.50 Bore, Dish, Set of 4 |
| Add-On |
JG1001-3445 |
| Add-On |
905-2250-15-51C |
| Add-On |
905-073-MW |
| Out of Stock Message |
Call for Availability |
| Title |
JE Pistons - Honda, F Series, 87.50 mm Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.905 |
| Product Market |
Sport Compact |
| Bore Diameter |
87.50 |
| Wrist Pin Outer Diameter |
0.905 |
| Piston Average Weight |
309 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Wall Thickness |
0.150 |
| Make |
HONDA |
| Compression Height |
1.181 |
| Piston Quantity |
4 |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
Yes |
| Engine - Web |
F Series |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Material |
2618 |
| Industry |
Automotive |
| Oil Ring Thickness |
0.111 |
| Second Compression Ring Thickness |
0.0480 |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Cylinder Head |
F20C1 |
| Piston Volume |
-11.00 |
| Wrist Pin Length |
2.250 |
| Engine |
F SERIES |
| Piston Pin Material |
5115 |
| Title - Web |
JE Pistons Honda F Series Piston Kit - 87.50 mm Bore - 1.181 in. CH, -11.00 CC |
| Ringset Included |
Yes |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Honda |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
