As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan QR25DE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.504 Bore, 1.260 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Nissan, QR25DE, 3.504 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Nissan QR25DE, 89.00 Bore, Dish, Set of 4 |
| Piston Pin Outside Diameter |
0.787 |
| Oil Ring Thickness |
0.111 |
| Make |
NISSAN |
| Forging Type |
Round |
| Piston Pin Material |
5115 |
| Compression Height |
1.260 |
| Title |
JE Pistons - Nissan, QR25DE, 89.00 mm Bore, Piston Kit |
| Bore Diameter |
89.00 |
| Piston Head Type |
Dish |
| Piston Average Weight |
347 |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.787 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
Yes |
| Piston Pin Wall Thickness |
0.180 |
| Piston Series |
JE Pistons |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Quantity |
4 |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
Sport Compact |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Length |
2.250 |
| Engine - Web |
QR25DE |
| Add-On |
787-050-MW |
| Piston Volume |
-15.40 |
| Cylinder Head |
2.5L QR25 |
| Industry |
Automotive |
| Engine |
QR25DE |
| Add-On |
JG1001-3504 |
| Add-On |
787-2250-18-51C |
| Title - Web |
JE Pistons Nissan QR25DE Piston Kit - 89.00 mm Bore - 1.260 in. CH, -15.40 CC |
| Piston Material |
2618 |
| Second Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Make - Web |
Nissan |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
