As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ257 Stroker |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.937 Bore, 1.130 CD, 0.905 Pin, Set of 4. |
| Description_EXT |
JE, Subaru, EJ Series, 3.937 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Subaru EJ257, 100.00 Bore, Dish, Set of 4 |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Piston Pin Outside Diameter |
0.905 |
| Wrist Pin Outer Diameter |
0.905 |
| Piston Pin Wall Thickness |
0.180 |
| Make |
SUBARU |
| Engine |
EJ SERIES |
| Piston Series |
JE Pistons |
| Forging Type |
FSR |
| Engine - Web |
EJ Series |
| Piston Pin Material |
5115 |
| Product Market |
Sport Compact |
| Compression Height |
1.130 |
| Oil Ring Thickness |
0.0995 |
| Piston Average Weight |
396 |
| Top Compression Ring Thickness |
0.0480 |
| Title |
JE Pistons - Subaru, EJ Series, 100.00 mm Bore, Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
Yes |
| Bore Diameter |
100.00 |
| Piston Quantity |
4 |
| Wrist Pin Wall Thickness |
0.180 |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
EJ257 STI |
| Product Type |
Engine Piston Kit |
| Title - Web |
JE Pistons Subaru EJ Series Piston Kit - 100.00 mm Bore - 1.130 in. CH, -21.50 CC |
| Piston Material |
2618 |
| Add-On |
JG4901-3937 |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
905-042-CT |
| Piston Volume |
-21.50 |
| Prop 65 Yes/No |
Yes |
| Add-On |
905-2250-18-51S |
| Industry |
Automotive |
| Piston Pin Length |
2.250 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Make - Web |
Subaru |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
