Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 502 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Dome, 4.470 Bore, 1.645 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.470 in. Bore, 1.645 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 502, 4.470 Bore, Dome, Set of 8 |
| Piston Pin Length |
2.930 |
| Piston Average Weight |
699 |
| Product Type |
Engine Piston Kit |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Prop 65 (C, R or CR) |
CR |
| Bore Diameter |
4.470 |
| Piston Volume |
1.00 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Material |
4032 |
| Industry |
Automotive |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.930 |
| Add-On |
990-2930-15-51S |
| Prop 65 Yes/No |
Yes |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.470 in. Bore - 1.645 in. CH, 1.00 CC |
| Cylinder Head |
OPEN CHAMBER |
| Add-On |
S100S8-4470-5 |
| Piston Head Type |
Dome |
| Second Compression Ring Thickness |
0.0640 |
| Engine |
Big Block |
| Add-On |
990-042-CS |
| Make - Web |
Chevrolet |
| Ringset Included |
No |
| Make |
CHEVROLET |
| Title |
SRP - Chevrolet, Big Block, 4.470 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.990 |
| Oil Ring Thickness |
0.188 |
| Piston Series |
SRP |
| Compression Height |
1.645 |
| Piston Pin Material |
5115 |
| Forging Type |
Round |
| Engine Type |
ICE |
| Product Market |
Domestic |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Big Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
