As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.8L VR6 24V 92-99 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.228 Bore, 1.686 CD, 0.787 Pin, Set of 6. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, VW, 2.8L VR6 24V, 3.228 in. Bore, 11.60:1, Flat Top, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Volkswagen 2.8L 12V VR6, 82.00 Bore, Flat, Set of 6 |
| Piston Pin Material |
5115 |
| Engine |
2.8L VR6 24V |
| Product Market |
European |
| Piston Pin Length |
2.250 |
| Ringset Included |
Yes |
| Compression Height |
1.686 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Wall Thickness |
0.180 |
| Forging Type |
Round |
| Piston Head Type |
Flat |
| Make |
VOLKSWAGEN |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.787 |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.787 |
| Engine - Web |
2.8L VR6 24V |
| Piston Volume |
-3.50 |
| Second Compression Ring Thickness |
0.0480 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Series |
JE Pistons |
| Title |
JE Pistons - Volkswagen, 2.8L VR6 24V, 82.00 mm Bore, Piston Kit |
| Piston Quantity |
6 |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Make - Web |
Volkswagen |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
JG1001-3228 |
| Title - Web |
JE Pistons Volkswagen 2.8L VR6 24V Piston Kit - 82.00 mm Bore - 1.686 in. CH, -3.50 CC |
| Piston Average Weight |
358 |
| Add-On |
787-2250-18-51C |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
24V VR6 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Add-On |
787-050-MW |
| Bore Diameter |
82.00 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
