As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.8L VR6 24V 92-99 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.209 Bore, 1.684 CD, 0.787 Pin, Set of 6. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, VW, 2.8L VR6 24V, 3.209 in. Bore, 11.50:1, Flat Top, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Volkswagen 2.8L 12V VR6, 81.50 Bore, Flat, Set of 6 |
| Add-On |
JG1001-3209 |
| Add-On |
787-050-MW |
| Add-On |
787-2250-18-51C |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Volkswagen 2.8L VR6 24V Piston Kit - 81.50 mm Bore - 1.684 in. CH, -3.50 CC |
| Prop 65 Yes/No |
Yes |
| Ring Set Included |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
355 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Pin Outside Diameter |
0.787 |
| Bore Diameter |
81.50 |
| Product Market |
European |
| Piston Volume |
-3.50 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.250 |
| Top Compression Ring Thickness |
0.0400 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Second Compression Ring Thickness |
0.0480 |
| Compression Height |
1.684 |
| Piston Quantity |
6 |
| Cylinder Head |
24V VR6 |
| Title |
JE Pistons - Volkswagen, 2.8L VR6 24V, 81.50 mm Bore, Piston Kit |
| Engine - Web |
2.8L VR6 24V |
| Make - Web |
Volkswagen |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
JE Pistons |
| Piston Pin Wall Thickness |
0.180 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Engine Type |
ICE |
| Make |
VOLKSWAGEN |
| Piston Pin Length |
2.250 |
| Engine |
2.8L VR6 24V |
| Forging Type |
Round |
| Ringset Included |
Yes |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.787 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
