As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 3.2L VR6 R32 24V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.346 Bore, 1.594 CD, 0.787 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, VW, 3.2L VR6 24V, 3.346 in. Bore, 11.50:1, Flat Top, 6 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Volkswagen 3.2L R32 24V VR6, 85.00 Bore, Flat, Set of 6 |
| Wrist Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Bore Diameter |
85.00 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Piston Volume |
-7.90 |
| Piston Quantity |
6 |
| Prop 65 (C, R or CR) |
CR |
| Compression Height |
1.594 |
| Piston Average Weight |
354 |
| Make |
VOLKSWAGEN |
| Piston Pin Outside Diameter |
0.787 |
| Add-On |
JG1001-3346 |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0400 |
| Ringset Included |
Yes |
| Cylinder Head |
R32 VR6 |
| Add-On |
787-050-MW |
| Piston Material |
2618 |
| Title |
JE Pistons - Volkswagen, 3.2L VR6 24V, 85.00 mm Bore, Piston Kit |
| Add-On |
787-2250-18-51C |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Engine |
3.2L VR6 24V |
| Product Market |
European |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine - Web |
3.2L VR6 24V |
| Title - Web |
JE Pistons Volkswagen 3.2L VR6 24V Piston Kit - 85.00 mm Bore - 1.594 in. CH, -7.90 CC |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Flat |
| Piston Pin Wall Thickness |
0.180 |
| Forging Type |
Round |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.787 |
| Wrist Pin Wall Thickness |
0.180 |
| Make - Web |
Volkswagen |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
