Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford 428 FE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.155 Bore, 1.325 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Ford, Big Block Ford FE, 4.155 in. Bore, 1.325 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Ford 428 FE, 4.155 Bore, Dish, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Forging Type |
FSR |
| Piston Pin Outside Diameter |
0.990 |
| Wrist Pin Outer Diameter |
0.990 |
| Engine Type |
ICE |
| Make |
FORD |
| Piston Head Type |
Dish |
| Piston Series |
SRP |
| Compression Height |
1.325 |
| Product Market |
Domestic |
| Piston Average Weight |
470 |
| Title |
SRP - Ford, Big Block FE, 4.155 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
No |
| Top Compression Ring Thickness |
0.0640 |
| Engine |
Big Block FE |
| Oil Ring Thickness |
0.188 |
| Bore Diameter |
4.155 |
| Piston Pin Material |
5115 |
| Engine - Web |
Big Block FE |
| Wrist Pin Wall Thickness |
0.150 |
| Product Type |
Engine Piston Kit |
| Out of Stock Message |
Call for Availability |
| Add-On |
990-042-CS |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-28.00 |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
S100S8-4155-5 |
| Title - Web |
SRP Ford Big Block FE Piston Kit - 4.155 in. Bore - 1.325 in. CH, -28.00 CC |
| Industry |
Automotive |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Add-On |
990-2750-15-51S |
| Piston Material |
4032 |
| Cylinder Head |
EDEL 6007/08 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.750 |
| Wrist Pin Length |
2.750 |
| Make - Web |
Ford |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
