Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford 390 FE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.080 Bore, 1.325 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Big Block Ford FE, 4.080 in. Bore, 1.325 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 390 FE, 4.080 Bore, Dish, Set of 8 |
| Title - Web |
SRP Ford Big Block FE Piston Kit - 4.080 in. Bore - 1.325 in. CH, -26.00 CC |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Piston Material |
4032 |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
EDEL 6007/08 |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Piston Volume |
-26.00 |
| Add-On |
990-042-CS |
| Prop 65 Yes/No |
Yes |
| Add-On |
990-2750-15-51S |
| Piston Pin Material |
5115 |
| Engine |
Big Block FE |
| Add-On |
J100F8-4080-5 |
| Second Compression Ring Thickness |
0.0640 |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.750 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Forging Type |
FSR |
| Top Compression Ring Thickness |
0.0640 |
| Piston Average Weight |
463 |
| Piston Series |
SRP |
| Oil Ring Thickness |
0.188 |
| Bore Diameter |
4.080 |
| Piston Pin Wall Thickness |
0.150 |
| Title |
SRP - Ford, Big Block FE, 4.080 in. Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.990 |
| Product Market |
Domestic |
| Piston Head Type |
Dish |
| Ringset Included |
No |
| Compression Height |
1.325 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Make |
FORD |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Big Block FE |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
