SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford 4.6L Modular 2V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 3.572 Bore, 1.220 CD, 0.866 Pin, Set of 8. |
| Description_EXT |
SRP Pro 4032, Ford, Modular Ford, 3.572 in. Bore, 1.220 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP Pro, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 4.6L Modular, 3.572 Bore, Flat, Set of 8 |
| Prop 65 Yes/No |
Yes |
| Add-On |
866-063-MW |
| Add-On |
JG3208-3571-0 |
| Industry |
Automotive |
| Add-On |
866-2250-15-51C |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Engine |
Modular |
| Piston Volume |
-3.00 |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Piston Material |
4032 |
| Second Compression Ring Thickness |
0.0600 |
| Title - Web |
SRP Pro 4032 Ford Modular Piston Kit - 3.572 in. Bore - 1.220 in. CH, -3.00 CC |
| Cylinder Head |
MODULAR 4.6 2V |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Piston Series |
SRP Pro 4032 |
| Title |
SRP Pro 4032 - Ford, Modular, 3.572 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
3.572 |
| Piston Head Type |
Flat |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Oil Ring Thickness |
0.119 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Average Weight |
341 |
| Compression Height |
1.220 |
| Make |
FORD |
| Wrist Pin Length |
2.250 |
| Engine - Web |
Modular |
| Ring Set Included |
Yes |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0480 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
12.0000 |
