As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Mazda 1.8L BP Miata |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.287 Bore, 1.205 CD, 0.787 Pin, Set of 4. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Mazda, BP Series, 3.287 in. Bore, 9.00:1, Flat Top, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Mazda 1.8L BP, 83.50 Bore, Flat, Set of 4 |
| Product Type |
Engine Piston Kit |
| Forging Type |
Round |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.787 |
| Oil Ring Thickness |
0.111 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.180 |
| Ring Set Included |
Yes |
| Compression Height |
1.205 |
| Piston Volume |
-2.00 |
| Title |
JE Pistons - Mazda, BP Series, 83.50 mm Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.180 |
| Engine Type |
ICE |
| Piston Average Weight |
294 |
| Piston Series |
JE Pistons |
| Engine - Web |
BP Series |
| Title - Web |
JE Pistons Mazda BP Series Piston Kit - 83.50 mm Bore - 1.205 in. CH, -2.00 CC |
| Make |
MAZDA |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
787-2250-18-51C |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
787-050-MW |
| Cylinder Head |
1.8 BP MIATA |
| Engine |
BP SERIES |
| Prop 65 Yes/No |
Yes |
| Add-On |
JG1001-3287 |
| Piston Quantity |
4 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
Yes |
| Bore Diameter |
83.50 |
| Product Market |
Sport Compact |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Mazda |
| Wrist Pin Outer Diameter |
0.787 |
| Industry |
Automotive |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Flat |
| Piston Material |
2618 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
