As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford Small Block NASCAR Canada |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 4.030 Bore, 1.769 CD, 0.912 Pin, Set of 8. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Ford, Small Block Ford, 4.030 in. Bore, 1.769 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Ford NASCAR Canada, 4.030 Bore, Dish, Set of 8 |
| Make |
FORD |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Pin Wall Thickness |
0.140 |
| Piston Quantity |
8 |
| Wrist Pin Outer Diameter |
0.912 |
| Piston Pin Outside Diameter |
0.912 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.500 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Product Market |
Domestic |
| Add-On |
927-042-CS |
| Industry |
Automotive |
| Compression Height |
1.769 |
| Piston Volume |
-14.00 |
| Bore Diameter |
4.030 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Product Type |
Engine Piston Kit |
| Piston Average Weight |
530 |
| Top Compression Ring Thickness |
0.0640 |
| Add-On |
J10008-4030-5 |
| Out of Stock Message |
Call for Availability |
| Add-On |
912-2500-14-51S |
| Title |
JE Pistons - Ford, Small Block, 4.030 in. Bore, Piston Kit |
| Piston Material |
2618 |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.140 |
| Piston Pin Material |
5115 |
| Engine |
Small Block |
| Piston Pin Length |
2.500 |
| Oil Ring Thickness |
0.188 |
| Piston Head Type |
Dish |
| Second Compression Ring Thickness |
0.0640 |
| Ringset Included |
No |
| Forging Type |
Round |
| Engine Type |
ICE |
| Title - Web |
JE Pistons Ford Small Block Piston Kit - 4.030 in. Bore - 1.769 in. CH, -14.00 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
JE Pistons |
| Make - Web |
Ford |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
