As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 502 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.610 Bore, 1.120 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.610 in. Bore, 1.120 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 502, 4.610 Bore, Dome, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Compression Height |
1.120 |
| Make |
CHEVROLET |
| Wrist Pin Length |
2.930 |
| Piston Quantity |
8 |
| Piston Pin Outside Diameter |
0.990 |
| Title |
JE Pistons - Chevrolet, Big Block, 4.610 in. Bore, Piston Kit |
| Second Compression Ring Thickness |
0.0440 |
| Top Compression Ring Thickness |
0.0435 |
| Piston Volume |
46.00 |
| Engine - Web |
Big Block |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Bore Diameter |
4.610 |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG7708-4610-5 |
| Prop 65 Yes/No |
Yes |
| Add-On |
990-2930-18-51S |
| Product Market |
Domestic |
| Industry |
Automotive |
| Piston Average Weight |
596 |
| Add-On |
990-042-CS |
| Ringset Included |
No |
| Piston Head Type |
Dome |
| Engine |
Big Block |
| Cylinder Head |
OPEN CHAMBER |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.149 |
| Piston Series |
JE Pistons |
| Piston Pin Length |
2.930 |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.610 in. Bore - 1.120 in. CH, 46.00 CC |
| Piston Pin Wall Thickness |
0.180 |
| Forging Type |
Round |
| Wrist Pin Outer Diameter |
0.990 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Wall Thickness |
0.180 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
