As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 502 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.560 Bore, 1.060 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.560 in. Bore, 1.060 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Chevrolet 502, 4.560 Bore, Dome, Set of 8 |
| Wrist Pin Wall Thickness |
0.180 |
| Make |
CHEVROLET |
| Oil Ring Thickness |
0.149 |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.180 |
| Compression Height |
1.060 |
| Title |
JE Pistons - Chevrolet, Big Block, 4.560 in. Bore, Piston Kit |
| Forging Type |
Round |
| Wrist Pin Outer Diameter |
0.990 |
| Engine - Web |
Big Block |
| Piston Average Weight |
551 |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.560 |
| Top Compression Ring Thickness |
0.0435 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Quantity |
8 |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
No |
| Wrist Pin Length |
2.930 |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dome |
| Piston Material |
2618 |
| Add-On |
JG7708-4560-5 |
| Piston Series |
JE Pistons |
| Piston Pin Outside Diameter |
0.990 |
| Cylinder Head |
OPEN CHAMBER |
| Add-On |
990-2930-18-51S |
| Second Compression Ring Thickness |
0.0440 |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.560 in. Bore - 1.060 in. CH, 43.00 CC |
| Piston Volume |
43.00 |
| Add-On |
990-042-CS |
| Industry |
Automotive |
| Engine |
Big Block |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.930 |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
