As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chrysler 2.0L ECB/ECC |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.484 Bore, 1.236 CD, 0.827 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Chrysler, ECB/ECC, 3.484 in. Bore, 10.50:1, Dome, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Chrysler 2.0L ECB/ECC, 88.50 Bore, Dome, Set of 4 |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Forging Type |
Round |
| Piston Head Type |
Dome |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Engine |
ECB/ECC |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Make |
CHRYSLER |
| Piston Pin Length |
2.250 |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.827 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
827-2250-15-51C |
| Bore Diameter |
88.50 |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Quantity |
4 |
| Title - Web |
JE Pistons Chrysler ECB/ECC Piston Kit - 88.50 mm Bore - 1.236 in. CH, 7.10 CC |
| Piston Volume |
7.10 |
| Product Market |
Sport Compact |
| Add-On |
827-063-MW |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.827 |
| Product Type |
Engine Piston Kit |
| Add-On |
JG1001-3484 |
| Piston Average Weight |
351 |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Engine - Web |
ECB/ECC |
| Wrist Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0400 |
| Cylinder Head |
ECB/ECC |
| Title |
JE Pistons - Chrysler, ECB/ECC, 88.50 mm Bore, Piston Kit |
| Industry |
Automotive |
| Piston Material |
2618 |
| Compression Height |
1.236 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chrysler |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
