As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_DEF |
Engine Piston Kit |
| Description_ASM |
Nissan VQ35DE |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.760 Bore, 1.165 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, Nissan, VQ35DE, 3.760 in. Bore, 8.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Nissan VQ35DE, 95.50 Bore, Dish, Set of 6 |
| Make |
NISSAN |
| Ringset Included |
Yes |
| Oil Ring Thickness |
0.0995 |
| Piston Series |
JE Pistons |
| Piston Head Type |
Dish |
| Wrist Pin Wall Thickness |
0.150 |
| Compression Height |
1.165 |
| Top Compression Ring Thickness |
0.0480 |
| Engine |
VQ35DE |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Engine Type |
ICE |
| Piston Pin Length |
2.500 |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
Round |
| Wrist Pin Outer Diameter |
0.866 |
| Ring Set Included |
Yes |
| Piston Material |
2618 |
| Piston Average Weight |
380 |
| Industry |
Automotive |
| Product Type |
Engine Piston Kit |
| Add-On |
JC2806-3760 |
| Add-On |
866-063-MW |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
0.866 |
| Out of Stock Message |
Call for Availability |
| Title |
JE Pistons - Nissan, VQ35DE, 95.50 mm Bore, Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Nissan VQ35DE Piston Kit - 95.50 mm Bore - 1.165 in. CH, -12.30 CC |
| Bore Diameter |
95.50 |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
866-2500-15-51C |
| Piston Quantity |
6 |
| Piston Volume |
-12.30 |
| Cylinder Head |
VQ35DE 3.5L |
| Wrist Pin Length |
2.500 |
| Engine - Web |
VQ35DE |
| Make - Web |
Nissan |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
