Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Small Block 340 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.030 Bore, 1.460 CD, 0.984 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chrysler, Small Block Chrysler, 4.030 in. Bore, 1.460 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Chrysler 340, 4.030 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
4.030 |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.984 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Piston Average Weight |
457 |
| Piston Head Type |
Dish |
| Oil Ring Thickness |
0.188 |
| Piston Volume |
-17.00 |
| Top Compression Ring Thickness |
0.0640 |
| Forging Type |
FSR |
| Make |
CHRYSLER |
| Engine - Web |
Small Block |
| Ring Set Included |
No |
| Title - Web |
SRP Chrysler Small Block Piston Kit - 4.030 in. Bore - 1.460 in. CH, -17.00 CC |
| Add-On |
990-042-CS |
| Piston Material |
4032 |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
No |
| Engine |
Small Block |
| Add-On |
S100S8-4030-5 |
| Cylinder Head |
340 WEDGE |
| Piston Pin Length |
2.750 |
| Compression Height |
1.460 |
| Prop 65 Yes/No |
Yes |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Add-On |
984-2750-15-51S |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Title |
SRP - Chrysler, Small Block, 4.030 in. Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.984 |
| Product Type |
Engine Piston Kit |
| Piston Series |
SRP |
| Wrist Pin Length |
2.750 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
