As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 500 Big Duke/Chief |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 4.600 Bore, 1.120 CD, 0.990 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.600 in. Bore, 1.120 CD, Dome, Single Piston |
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Chevrolet 500, 4.600 Bore, Dome, Set of 1 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Piston Pin Outside Diameter |
0.990 |
| Engine Type |
ICE |
| Piston Head Type |
Dome |
| Wrist Pin Outer Diameter |
0.990 |
| Oil Ring Thickness |
0.218 |
| Compression Height |
1.120 |
| Piston Series |
JE Pistons |
| Make |
CHEVROLET |
| Piston Quantity |
1 |
| Forging Type |
Round |
| Piston Pin Wall Thickness |
0.150 |
| Title |
JE Pistons - Chevrolet, Big Block, 4.600 in. Bore, Piston |
| Piston Average Weight |
605 |
| Bore Diameter |
4.600 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Top Compression Ring Thickness |
0.0435 |
| Ringset Included |
No |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.150 |
| Cylinder Head |
BIG CHIEF |
| Add-On |
J200U8-4600-5 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Piston Pin Length |
2.930 |
| Piston Volume |
19.00 |
| Out of Stock Message |
Call for Availability |
| Add-On |
990-042-CS |
| Prop 65 Yes/No |
Yes |
| Add-On |
990-2930-15-51S |
| Piston Material |
2618 |
| Second Compression Ring Thickness |
0.0640 |
| Engine |
Big Block |
| Title - Web |
JE Pistons Chevrolet Big Block Piston - 4.600 in. Bore - 1.120 in. CH, 19.00 CC |
| Industry |
Automotive |
| Product Type |
Engine Piston |
| Ring Set Included |
No |
| Wrist Pin Length |
2.930 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
2.0000 |
