Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.350 Bore, 2.062 CD, 1.094 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.350 in. Bore, 2.062 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.350 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Make |
CHRYSLER |
| Piston Head Type |
Flat |
| Wrist Pin Outer Diameter |
1.094 |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Piston Series |
SRP |
| Compression Height |
2.062 |
| Engine |
Big Block |
| Title |
SRP - Chrysler, Big Block, 4.350 in. Bore, Piston Kit |
| Forging Type |
FSR |
| Ringset Included |
No |
| Oil Ring Thickness |
0.188 |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Average Weight |
702 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Length |
2.930 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.350 in. Bore - 2.062 in. CH, -6.00 CC |
| Bore Diameter |
4.350 |
| Cylinder Head |
440 WEDGE |
| Top Compression Ring Thickness |
0.0640 |
| Piston Material |
4032 |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
No |
| Make - Web |
Chrysler |
| Wrist Pin Length |
2.930 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Out of Stock Message |
Call for Availability |
| Piston Volume |
-6.00 |
| Add-On |
094-2930-15-51S |
| Add-On |
S100S8-4350-5 |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
1.094 |
| Industry |
Automotive |
| Add-On |
094-037-CS |
| Prop 65 (C, R or CR) |
CR |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
