As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DES |
Piston Single, 2618, Dome, 4.130 Bore, 1.125 CD, 0.927 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.130 in. Bore, 1.125 CD, Dome, Right Piston |
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Chevrolet 400, 4.130 Bore, Dome, Set of 1 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Piston Pin Outside Diameter |
0.927 |
| Bore Diameter |
4.130 |
| Product Market |
Domestic |
| Piston Orientation |
Right |
| Top Compression Ring Thickness |
0.0640 |
| Add-On |
927-073-AS |
| Title |
JE Pistons - Chevrolet, Small Block, 4.130 in. Bore, Piston |
| Add-On |
J10008-4130-5 |
| Piston Average Weight |
461 |
| Make |
CHEVROLET |
| Out of Stock Message |
Call for Availability |
| Add-On |
927-2750-15-51S |
| Piston Volume |
3.30 |
| Compression Height |
1.125 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Piston Quantity |
1 |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
No |
| Cylinder Head |
CHEVROLET 18 DEG |
| Engine |
Small Block |
| Title - Web |
JE Pistons Chevrolet Small Block Piston - 4.130 in. Bore - 1.125 in. CH, 3.30 CC |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
Round |
| Piston Head Type |
Dome |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Second Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston |
| Oil Ring Thickness |
0.218 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Piston Pin Material |
5115 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Make - Web |
Chevrolet |
| Wrist Pin Length |
2.750 |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
2.0000 |
