As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.165 in. Bore, 1.000 CD, Dome, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.165 Bore, 1.000 CD, 0.927 Pin, Set of 8. |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 400, 4.165 Bore, Dome, Set of 8 |
| Product Market |
Domestic |
| Ring Set Included |
No |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Wrist Pin Length |
2.750 |
| Product Type |
Engine Piston Kit |
| Top Compression Ring Thickness |
0.0640 |
| Title |
JE Pistons - Chevrolet, Small Block, 4.165 in. Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.927 |
| Piston Quantity |
8 |
| Piston Volume |
3.30 |
| Compression Height |
1.000 |
| Piston Average Weight |
450 |
| Engine - Web |
Small Block |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 Yes/No |
Yes |
| Bore Diameter |
4.165 |
| Add-On |
927-073-AS |
| Cylinder Head |
CHEVROLET 18 DEG |
| Add-On |
927-2750-15-51S |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
J10008-4165-5 |
| Second Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Ringset Included |
No |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
Round |
| Out of Stock Message |
Call for Availability |
| Engine |
Small Block |
| Oil Ring Thickness |
0.218 |
| Piston Pin Length |
2.750 |
| Piston Pin Material |
5115 |
| Make |
CHEVROLET |
| Title - Web |
JE Pistons Chevrolet Small Block Piston Kit - 4.165 in. Bore - 1.000 in. CH, 3.30 CC |
| Engine Type |
ICE |
| Piston Material |
2618 |
| Piston Series |
JE Pistons |
| Piston Head Type |
Dome |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
