As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda H23A1 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.445 Bore, 1.204 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
Piston Set, 2618, Inv Dome/Dish, 3.445 Bore, 1.204 CD, 0.866 Pin Dia, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Honda H23, 87.50 Bore, Dish, Set of 4 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Series |
JE Pistons |
| Wrist Pin Wall Thickness |
0.150 |
| Bore Diameter |
87.50 |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.866 |
| Compression Height |
1.204 |
| Oil Ring Thickness |
0.111 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Forging Type |
Round |
| Title |
JE Pistons - Honda, H Series, 87.50 mm Bore, Piston Kit |
| Engine - Web |
H Series |
| Piston Pin Outside Diameter |
0.866 |
| Piston Quantity |
4 |
| Piston Volume |
-11.90 |
| Piston Average Weight |
328 |
| Product Type |
Engine Piston Kit |
| Make |
HONDA |
| Product Market |
Sport Compact |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0480 |
| Piston Pin Material |
5115 |
| Ring Set Included |
Yes |
| Ringset Included |
Yes |
| Add-On |
JC8A04-3445 |
| Title - Web |
JE Pistons Honda H Series Piston Kit - 87.50 mm Bore - 1.204 in. CH, -11.90 CC |
| Piston Head Type |
Dish |
| Add-On |
866-063-MW |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
866-2250-15-51C |
| Engine |
H SERIES |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
2.3L 4 VALVE |
| Industry |
Automotive |
| Wrist Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Honda |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
6.0000 |
