As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K20A2 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.386 Bore, 1.176 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
Piston Set, 2618, Dome, 3.386 Bore, 1.176 CD, 0.866 Pin Dia, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda K20A2, 86.00 Bore, Dome, Set of 4 |
| Add-On |
866-063-MW |
| Add-On |
JC2704-3386 |
| Add-On |
866-2250-15-51C |
| Title - Web |
JE Pistons Acura K Series Piston Kit - 86.00 mm Bore - 1.176 in. CH, 4.60 CC |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
Yes |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Engine |
K Series |
| Make - Web |
Acura |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Dome |
| Cylinder Head |
K20 |
| Make |
ACURA |
| Piston Pin Outside Diameter |
0.866 |
| Piston Pin Wall Thickness |
0.150 |
| Product Market |
Sport Compact |
| Title |
JE Pistons - Acura, K Series, 86.00 mm Bore, Piston Kit |
| Compression Height |
1.176 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Engine Type |
ICE |
| Piston Volume |
4.60 |
| Piston Series |
JE Pistons |
| Top Compression Ring Thickness |
0.0480 |
| Forging Type |
Round |
| Product Type |
Engine Piston Kit |
| Oil Ring Thickness |
0.119 |
| Industry |
Automotive |
| Piston Pin Material |
5115 |
| Piston Quantity |
4 |
| Piston Material |
2618 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.250 |
| Engine - Web |
K Series |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Average Weight |
307 |
| Prop 65 (C, R or CR) |
CR |
| Bore Diameter |
86.00 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
