As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.035 in. Bore, 1.125 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 4.035 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 350, 4.035 Bore, Flat, Set of 8 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Wrist Pin Outer Diameter |
0.927 |
| Piston Series |
JE Pistons |
| Make |
CHEVROLET |
| Top Compression Ring Thickness |
0.0640 |
| Piston Average Weight |
390 |
| Piston Pin Material |
5115 |
| Wrist Pin Wall Thickness |
0.150 |
| Title |
JE Pistons - Chevrolet, Small Block, 4.035 in. Bore, Piston Kit |
| Bore Diameter |
4.035 |
| Piston Pin Outside Diameter |
0.927 |
| Piston Material |
2618 |
| Compression Height |
1.125 |
| Product Market |
Domestic |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.119 |
| Product Type |
Engine Piston Kit |
| Forging Type |
Round |
| Piston Volume |
-4.30 |
| Piston Quantity |
8 |
| Piston Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Ring Set Included |
No |
| Wrist Pin Length |
2.500 |
| Add-On |
927-2500-15-51S |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Prop 65 (C, R or CR) |
CR |
| Engine |
Small Block |
| Industry |
Automotive |
| Add-On |
J30008-4030-5 |
| Title - Web |
JE Pistons Chevrolet Small Block Piston Kit - 4.035 in. Bore - 1.125 in. CH, -4.30 CC |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.500 |
| Piston Head Type |
Flat |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
927-042-CS |
| Prop 65 Yes/No |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
