As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 4.560 Bore, 1.270 CD, 0.990 Pin, Set of 1. |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.560 in. Bore, 1.270 CD, Dome, Single Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Chevrolet 454, 4.560 Bore, Dome, Set of 1 |
| Description_SHO |
Piston |
| Product Type |
Engine Piston |
| Industry |
Automotive |
| Add-On |
990-2930-15-51S |
| Piston Quantity |
1 |
| Add-On |
J20008-4560-5 |
| Add-On |
990-042-CS |
| Wrist Pin Length |
2.930 |
| Ring Set Included |
No |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Piston Pin Length |
2.930 |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
2618 |
| Second Compression Ring Thickness |
0.0640 |
| Piston Volume |
13.00 |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Chevrolet Big Block Piston - 4.560 in. Bore - 1.270 in. CH, 13.00 CC |
| Cylinder Head |
BIG CHIEF |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine |
Big Block |
| Piston Head Type |
Dome |
| Oil Ring Thickness |
0.218 |
| Make |
CHEVROLET |
| Forging Type |
Round |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Title |
JE Pistons - Chevrolet, Big Block, 4.560 in. Bore, Piston |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
0.990 |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
No |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Engine - Web |
Big Block |
| Top Compression Ring Thickness |
0.0436 |
| Product Market |
Domestic |
| Piston Average Weight |
625 |
| Compression Height |
1.270 |
| Piston Series |
JE Pistons |
| Bore Diameter |
4.560 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
2.0000 |
