Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DES |
Piston Set, 2618, Flat Top, 4.060 Bore, 1.550 CD, 0.927 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.060 in. Bore, 1.550 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chevrolet 350, 4.060 Bore, Flat, Set of 8 |
| Out of Stock Message |
Call for Availability |
| Industry |
Automotive |
| Add-On |
S100S8-4060-5 |
| Engine |
Small Block |
| Add-On |
927-042-CS |
| Add-On |
927-2500-15-51S |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 Yes/No |
Yes |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.060 in. Bore - 1.550 in. CH, -4.00 CC |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Cylinder Head |
STD CHEVROLET 23 DEG |
| Ringset Included |
No |
| Piston Pin Length |
2.500 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Oil Ring Thickness |
0.188 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Piston Material |
2618 |
| Piston Pin Outside Diameter |
0.927 |
| Compression Height |
1.550 |
| Top Compression Ring Thickness |
0.0640 |
| Forging Type |
FSR |
| Bore Diameter |
4.060 |
| Piston Series |
SRP |
| Piston Volume |
-4.00 |
| Title |
SRP - Chevrolet, Small Block, 4.060 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Product Market |
Domestic |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Make |
CHEVROLET |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Average Weight |
454 |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
No |
| Wrist Pin Length |
2.500 |
| Engine - Web |
Small Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
