Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Flat Top, 4.040 Bore, 1.125 CD, 0.927 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.040 in. Bore, 1.125 CD, Flat Top, Single Piston |
| Description_TLE |
Chevrolet 350, 4.040 Bore, Flat, Set of 1 |
| Description_SHO |
Piston |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Engine |
Small Block |
| Piston Head Type |
Flat |
| Piston Pin Length |
2.500 |
| Title - Web |
SRP Chevrolet Small Block Piston - 4.040 in. Bore - 1.125 in. CH, -4.00 CC |
| Engine Type |
ICE |
| Ringset Included |
No |
| Oil Ring Thickness |
0.188 |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.927 |
| Piston Average Weight |
371 |
| Piston Pin Wall Thickness |
0.150 |
| Prop 65 (C, R or CR) |
CR |
| Compression Height |
1.125 |
| Piston Series |
SRP |
| Second Compression Ring Thickness |
0.0640 |
| Top Compression Ring Thickness |
0.0640 |
| Title |
SRP - Chevrolet, Small Block, 4.040 in. Bore, Piston |
| Forging Type |
FSR |
| Make |
CHEVROLET |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Length |
2.500 |
| Make - Web |
Chevrolet |
| Ring Set Included |
No |
| Engine - Web |
Small Block |
| Product Type |
Engine Piston |
| Add-On |
927-042-CS |
| Product Market |
Domestic |
| Piston Volume |
-4.00 |
| Industry |
Automotive |
| Bore Diameter |
4.040 |
| Add-On |
S100S8-4040-5 |
| Cylinder Head |
STD CHEVROLET 23 DEG |
| Add-On |
927-2500-15-51S |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Single Replacement Pistons |
| Piston Material |
2618 |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
