Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.560 Bore, 1.395 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.560 in. Bore, 1.395 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 454, 4.560 Bore, Dome, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Engine |
Big Block |
| Prop 65 Yes/No |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ringset Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Pin Length |
2.930 |
| Second Compression Ring Thickness |
0.0640 |
| Make - Web |
Chevrolet |
| Piston Head Type |
Dome |
| Out of Stock Message |
Call for Availability |
| Forging Type |
FSR |
| Piston Series |
SRP |
| Oil Ring Thickness |
0.188 |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.560 in. Bore - 1.395 in. CH, 39.00 CC |
| Engine Type |
ICE |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
S100S8-4560-5 |
| Top Compression Ring Thickness |
0.0640 |
| Cylinder Head |
OPEN CHAMBER |
| Make |
CHEVROLET |
| Piston Average Weight |
672 |
| Compression Height |
1.395 |
| Add-On |
990-042-CS |
| Industry |
Automotive |
| Piston Pin Wall Thickness |
0.150 |
| Piston Volume |
39.00 |
| Bore Diameter |
4.560 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Piston Pin Material |
5115 |
| Piston Material |
2618 |
| Piston Pin Outside Diameter |
0.990 |
| Title |
SRP - Chevrolet, Big Block, 4.560 in. Bore, Piston Kit |
| Add-On |
990-2930-15-51S |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.990 |
| Ring Set Included |
No |
| Engine - Web |
Big Block |
| Wrist Pin Length |
2.930 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
